Quincy Air Compressor 4103D12VCB20M QT Max 10 HP 120 Gallon Two Stage 208V 3 Phase

Quincy 4103D12VCB20M QT MAX

The Quincy QT MAX 10 HP vertical compressor is engineered for heavy-duty, continuous-use environments. Its 120‑gallon ASME-certified tank provides substantial capacity to reduce cycle frequency, while the two‑stage, splash-lubricated cast‑iron pump delivers approximately 35 CFM at 175 PSI—ideal for demanding applications like blast cabinets, paint spray equipment, or busy auto shops. The oversized oil reservoir and efficient cooling system allow the unit to run cooler and quieter at reduced RPM, maximizing both longevity and energy efficiency.

Built with durability in mind, the compressor includes an aluminum head for optimal heat dissipation, ductile‑iron crankshaft, stainless steel reed valves, and industrial bearings designed for over 50,000 hours of service life. Safety and convenience features include a magnetic starter with thermal overload protection, an automatic electronic tank drain to prevent moisture buildup and rust, low‑oil shutoff, oil sight gauge for monitoring, and a high-efficiency finned intercooler to reduce interstage temperatures—all enclosed in a sturdy assembly for reliability.

The QT MAX 10 delivers a full 175 PSI pressure rating and integrates cooling strategies and lubrication engineering to minimize maintenance and extend uptime. Its vertical layout saves floor space without compromising stability or power. By standard, Quincy includes a one-year factory warranty on parts and labor. If the EWK‑4 Maintenance Kit is purchased at the time of sale and the compressor is registered within 10 days, the warranty package doubles to two years and the pump warranty extends to three years, including onsite parts and labor coverage. Click on the manual link below for warranty information.
