Quincy Air Compressor Pro 10 HP Two Stage 208V 3 Phase
Quincy 5103DS12HCA20 QP Pro 10-HP 120-Gallon Pressure Lubricated Two-Stage Air Compressor (208V 3-Phase)
The Quincy 3103DS12HCA20 QP Pro is designed to deliver dependable, high-volume compressed air for demanding industrial applications. Equipped with a 10 HP motor and an 80-gallon vertical tank, this unit provides steady airflow to support continuous use in manufacturing and automotive environments.
Its pressure-lubricated two-stage pump is built for long service life, with durable cast-iron components that withstand rigorous operating conditions. The compressor operates efficiently at 208 volts and Three Phase power, maintaining smooth performance while minimizing heat and wear.
Maintenance is simplified through automatic condensate drainage and reliable lubrication monitoring systems that help protect the pump and motor. Compact yet powerful, this compressor is well suited for shops and facilities requiring consistent, industrial-grade air supply.
Product Features
- Fully Pressure Lubricated 2-Stage Compressor
- Gerotor Positive Displacement Oil Pump
- Spin-On Oil filter
- Stainless Steel Reed Valves With Valve Bumpers
- Graphite Cylinder & Head Gaskets
- Electronically Balanced Fan-Type Cast Iron Flywheel
- Cast Iron Cylinders, High-Efficiency Fin & Tube Intercooler
- One Year Factory Warranty
Product Specifications
General Information
| Product Category | Air Compressor - Stationary |
Motor
| Voltage | 208 Volt AC |
| Phase | Three Phase |
| Magnetic Starter | Yes |
| Amp Draw | 32.2 |
| Recommended Breaker | Consult Certified Electrician |
Engine
| HP | 10 |
Pump
| CFM | 35 |
| CFM Rated @ | 175 PSI |
| Pump Material | Cast Iron w/ Aluminum Head |
| Max PSI | 175 PSI |
| Oil Sight Glass | Yes |
| Pump Type | Two-Stage |
| After Cooler | No |
| Pump Drive | Belt Drive |
| Oil Type | Oil Lubricated |
| Oil System | Splash Lubricated |
| Pump Low Oil Shut-off | No |
Tank
| Tank Size | 120 Gallons |
| Tank Outlet | 3/4 Inch |
| Electronic Drain Valve | No |
| Tank Orientation | Horizontal |
Accessories
| Air Dryer | No |
Overview
| Weight | 850 Pounds |
| Certification | ASME. UL, CSA |
| Consumer Warranty | 1 Year |
| Commercial Warranty | 1 Year |
| Product Length | 78 Inches |
| Product Width | 28 Inches |
| Product Height | 55 Inches |
| Power Type | Electric |
